Control Panel Bezel 1 Pump
The control panel consists of the buttons that spa owner uses to regulate the light and thermostat, as well as operate the jet pump(s).
The control panel is attached to the spa by two screws. Compatible with a variety of the 1994 to 2010 Hot Spring Highlife spa models.
*Check specs section for full list of compatible models and years. No longer comes with the LED light.
Specifications
| Make |
Model |
Date Range |
| Hot Spring |
Vanguard |
2001-2004 |
| Hot Spring |
Jetsetter |
1998-2008 |
| Hot Spring |
Prodigy |
1998-2008 |
| Hot Spring |
Sovereign |
1998-2008 |
| Hot Spring |
Classic |
1998-2000 |
| Hot Spring |
Highlife ILE |
2003 |
| Item |
|
Year Used |
Part # |
| 1a |
Control Panel 1 Jet Pump |
1998-2008 |
71510 |
| 1b |
Control Panel 2 Jet Pump |
1998-2008 |
71509 |
| 2a |
Control Head 1998-2000 Discontinued, Use 73225 |
1998-2000 |
71920 |
| 2b |
Control Head 2001-2008 |
2001-2008 |
73225 |
| 3 |
Light Cover |
1998-2008 |
37248 |
| 4 |
Screw 6-22 x 7/8 |
1998-2008 |
37265 |
| * |
Control Panel Mounting Screw |
1998-2008 |
37262 |
| * |
Harness Led Backlight |
1998-2008 |
37603 |
| * |
Backlight HSS Control Panel |
1998-2008 |
37611 |
* Non Illustrated Part
| Removal |
- Disconnect power to the spa.
- Carefully remove the dome light cover.
- Remove the two control panel mounting screws.
- Gently pull the control panel away from the spa only far enough to thread the panel back through the cutout and into the equipment compartment.
Caution: The fiber optic cables (if applicable) can be damaged or become dislodged by excessive pulling on the control panel.
- Access the IQ 2000 control box.
- Disconnect and remove the control panel ribbon cable (if applicable).
- Separate the control head from the control panel.
- To reinstall the control panel, reverse steps 1 to 7.
|
|
